Dimensions:

Mounting Surface To End Of Pedal: 17-1/2"

Pedal Pivot To Center Of Pedal: 15"

Master Cylinder Pivot To Center Of Pedal: 13-1/2"

Pedal Pad: 3-1/2" x 3-1/2" With Grip Tape

Specifications:

Pedal Arm: Steel

Master Cylinder Bracket: Billet Aluminum

Uses Standard 2-1/4" Vertical Bolt Pattern Cylinders

Uses 5/16" Bolts To Secure Master Cylinders

Includes Heavy Duty 7/16" Balance Bar

Balance Bar Is Machined Down On One Side 3/8"-24 Thread For Adjuster

Can be used with CNC1224 mounting plate

Can be used with CNC830 or CNC831 balance bar adjusters

Can be used with Tilton's 72-508, 72-509, or 72-408 balance bar adjusters
